Peekling engine

Add a small animated companion to a website without adding a backend or telemetry service. Peekling runs in the browser, keeps character Packs as data, and gives the host application control through one documented runtime API.

This monorepo contains the dependency-free browser runtime and separate tools for validating Configuration, Plans, and Packs before they reach a page.

Start with the runnable examples

Prerequisites:

• Node.js 22.14.0 or newer
• npm 11.16.0

From the repository root:

npm ci
npm run examples

Open http://127.0.0.1:4174. You should see four local examples, beginning with a character that follows the pointer. The example server builds the exact runtime in this checkout and generates a synthetic Pack in memory. It does not need an external character package or network service.

See the example learning path for what to try on each page.

Add Peekling to an application

Install the runtime as an application dependency:

npm install @peekling/runtime

Every instance needs a character selection. The example below selects a Pack served by the application and tells Vite to emit the required runtime stylesheet. Replace the Pack path with a valid character.json whose States include idle.

import { hatch } from "@peekling/runtime";
import peeklingStyles from "@peekling/runtime/peekling.css?url";

const companion = hatch({
  packUrl: "/peeklings/my-character/character.json",
  styles: { url: peeklingStyles },
  plan: {
    baseline: {
      channels: ["state"],
      state: { state: "idle" },
    },
  },
});

try {
  await companion.ready;
  console.log("Peekling is ready");
} catch (error) {
  console.error("Peekling could not start", error);
}

window.addEventListener("pagehide", () => companion.destroy(), { once: true });

Expected result: ready resolves after the Pack, atlas, and stylesheet have been validated and loaded. The instance renders the Pack's idle State until the Plan or a temporary Override selects another supported State.

For the standard website companion, replace the explicit Plan with preset: "companion". Named presets compile into the same canonical Plan. The character is draggable and throwable by default, and a character click toggles its owned content bubble. Product-specific motion remains plain JSON Plan data, including viewport traversal, host targets, jumps, and custom SVG paths.

For the complete Configuration shape, error behavior, Events, Effects, and content surfaces, read Configure Peekling.

How the engine fits together

Pack data --------+
                  +--> validate --> compile Plan --> evaluate --> Effects
Configuration ----+                           ^                     |     |
                                              |                     |     +--> host surfaces
Browser and application Events --> admission-+                     +--------> atlas renderer

Artists provide a data-only Pack. Developers provide Configuration, including one immutable baseline Plan. Peekling validates both, admits bounded browser and application Events, evaluates matching Rules, and composes Effects only when their presentation channels are compatible. Effects can update the character renderer or a trusted host-mounted surface.

This separation keeps character data away from executable host code. The execution model defines ordering, channel ownership, temporary Overrides, lifecycle behavior, and cleanup.

Choose an integration surface

Need	Surface	What it does
JavaScript or TypeScript application	hatch(configuration)	Creates one owned runtime instance
Browser-global script	Peekling.hatch(configuration)	Exposes the same hatch contract from the complete browser artifact
HTML-first page	<peekling-character>	Owns one hatch instance for each connected mount
Canvas character presentation	hatchCanvas(configuration)	Uses Canvas 2D with the same Plan, interaction, content, and lifecycle
Programmatic validation	@peekling/preflight	Checks bounded Configuration, Plan, and optional Pack data
Vite validation	@peekling/vite	Runs Preflight at startup, on watched JSON changes, and before builds
Command line and Pack authoring	peekling	Runs Doctor and the Pack creation, compilation, import, and validation tools

The ESM root has no registration side effects. Call definePeeklingElement() when an ESM application wants the Web Component. The complete browser artifact registers the component automatically when the name is free. Neither surface replaces an unrelated browser global or custom element.

Browser script and Web Component

Use exact version pins for external delivery. Replace both integrity placeholders with the values emitted by the release build, and replace the Pack path with a valid manifest hosted by the application:

<script
  defer
  src="https://cdn.jsdelivr.net/npm/@peekling/runtime@0.1.5/dist/peekling.min.js"
  integrity="sha384-<runtime-sri-from-build>"
  crossorigin="anonymous"
></script>
<peekling-character
  pack-url="/peeklings/my-character/character.json"
  styles-url="https://cdn.jsdelivr.net/npm/@peekling/runtime@0.1.5/dist/peekling.css"
  styles-integrity="sha256-<stylesheet-sri-from-build>"
></peekling-character>

Expected result: the complete browser artifact claims globalThis.Peekling and registers <peekling-character> when those names are free. The element creates one hatch-owned instance after the pinned runtime, stylesheet, and selected Pack pass their loading and integrity checks.

Character selection

Each mount must provide one of these inputs:

• character, for a name in the runtime's pinned registry
• packUrl, for a validated manifest URL
• pack, for inline Native or normalized Pack data

hatch("peek") is shorthand for the pinned peek registry entry. It performs a network request for the manifest and selected atlas. Self-hosted applications can use packUrl or inline Pack data instead.

The runtime verifies manifest and atlas integrity before decoding character art. An atlasUrl may point to a byte-identical mirror. It is not an image conversion hook. Density-variant Packs also require an explicit density when an atlas mirror is supplied.

Runtime safety

• Packs are data, never code. Pack strings do not enter HTML-parsing sinks.
• The runtime does not send telemetry and owns no network service.
• Strict Content Security Policy support does not require unsafe-inline or unsafe-eval.
• Closed Shadow DOM contains runtime presentation without pretending to be a security boundary.
• Paused, backgrounded, and dismissed instances stop ordinary animation, evaluation, and collection work.
• destroy() releases listeners, observers, timers, roots, and object URLs owned by that instance.
• Host mount functions remain trusted application code. Their failures are contained at the surface boundary where the browser permits it.

The detailed browser, CSP, CORS, iframe, top-layer, and host-layout boundaries are documented in Browser compatibility and hosting.

Packages

Package	Install role	Browser runtime graph
@peekling/runtime	Application dependency	Required when the application uses Peekling
@peekling/preflight	Development dependency	Excluded
@peekling/vite	Development dependency	Excluded
@peekling/cli	Development dependency or command-line tool	Excluded
@peekling/adapter-codex-pet	Optional interoperability dependency	Included only when the application imports it

Character artwork, website code, design-system sources, and framework-specific adapters are outside this repository. Nothing in those products is silently bundled into the runtime.

Validate a project before it runs

Doctor checks JSON Configuration and optional Pack data without importing application modules or contacting the network:

npm install --save-dev @peekling/cli @peekling/preflight
npx peekling doctor ./peekling.json --pack ./character.json
npx peekling doctor ./peekling.json --pack ./character.json --json

Vite applications can run the same semantic validation at startup, during watched JSON changes, and before production builds:

npm install --save-dev @peekling/vite

Read the @peekling/cli, @peekling/preflight, and @peekling/vite guides for complete examples.

Bundle budget

The complete browser artifact has separate gzip and Brotli release gates. The 0.1.5 record below measures the interaction and renderer release with the exact release toolchain and required reserve.

The recorded canonical delivery measurement is 38,428 bytes gzip and 33,684 bytes Brotli. Against the 40 KiB gzip and 40 KiB Brotli caps, that recorded build leaves 2,532 bytes of gzip headroom and 7,276 bytes of Brotli headroom. After the required 256-byte reserve, 2,276 gzip bytes and 7,020 Brotli bytes remain for that build.

Node 22.14.0, npm 11.16.0, and Node's default zlib compression define the exact release-size measurement environment. Other supported Node versions can run a local size check, but they do not certify the historical figures.

Develop and verify

Run the core repository gate:

npm ci
npm run check

npm run check maps to check:core. It covers formatting, build, lint, boundaries, workflow safety, package metadata, distribution contents, types, unit tests, bundle size, and the runtime performance smoke test.

Run browser behavior separately:

npm run test:browser

That Playwright command exercises Chromium, Firefox, and WebKit. The canonical browser performance gate is a separate release workflow described in Browser performance release evidence.

Useful focused commands:

Command	Purpose
npm run examples	Build and serve the local learning examples
npm run test:examples	Test example structure and Chromium behavior
npm run release:verify:packages	Build clean package archives and test consumer imports
npm run release:verify:local	Rehearse local release gates without remote assertions
npm run size	Check compressed runtime and ESM measurements

The release guide owns tagging, provenance, CI, and package publication procedure.

Documentation

Use the documentation map when you are not sure which guide owns a question.

Start here:

• Configure Peekling
• Runnable examples
• Troubleshooting
• Browser compatibility and hosting

Understand the engine:

• Execution model
• Character interaction and motion
• Engine design
• Schema and type references
• Browser performance release evidence

Work on the repository:

• Contributing
• Support policy
• Security policy
• Release guide
• Changelog
• Licensing and attribution

License

The engine and its original tooling are Apache-2.0. Character artwork keeps its own Pack license. See licensing and attribution and NOTICE for the repository boundary.
