Kairo

Open-Source On-Device RAG & Consultation Assistant for Android

Kairo is an open-source, modular, and privacy-first Android application designed for local Retrieval-Augmented Generation (RAG), clinical consultations, document synthesis, and conversational coding.

Running 100% on-device with zero telemetry and zero cloud API keys, Kairo executes quantized Large Language Models (GGUF format via llama.cpp) and an on-device hybrid retrieval engine (BM25 + Dense Embeddings) directly on mobile hardware.

---

✨ Features & Capabilities

• 🔒 100% Offline & Private: Zero data leaves your device. Model weights, chat history, and document extractions remain sandboxed in internal storage; retrieval indexes are rebuilt in-memory per session and never leave the device.
• 🩺 Multi-Persona Reasoning & Consultation Harness:
  • Clinical / Doctor Consultation: Tailored for healthcare providers to summarize clinical notes, review symptom timelines, and cross-examine patient records with structured grounding.
  • Code & Engineering: Optimized for software developers with complete code generation, syntax highlighting, and architectural reasoning.
  • Document Analyst: Deep academic, legal, and report synthesis with citation fidelity.
  • General Assistant: Everyday balanced conversational reasoning.
  • Custom System Instructions: Define your own domain-specific persona, formatting guidelines, and behavioral rules.
• ⚡ High-Throughput On-Device Inference:
  • SmolLM2 360M Instruct (Q4_K_M): ~12–18 tokens/second on mid-range ARM64 hardware with ultra-light battery consumption (~270 MB RAM).
  • SmolLM2 360M Instruct (Q8_0): High-precision 8-bit quantization for sensitive text analysis (~388 MB RAM).
  • Llama 3.2 1B Instruct (Q4_K_M): Meta's 1B model delivering complex instruction-following and grounded answers (~747 MB RAM).
  • Qwen 2.5 Coder 1.5B Instruct (Q4_K_M): High-tier coding and mathematical reasoning (~1.1 GB RAM).
• 🧠 Production-Grade Hybrid RAG Engine:
  • Hierarchical Breadcrumb Chunking: Preserves structural document context ([Source 1 | Chapter 2 > Section 3]).
  • Okapi BM25 Sparse Search: Zero-allocation inverted index for exact keywords, medical terms, and code symbols.
  • Dense Vector Embeddings: Cosine similarity against semantic representations.
  • Reciprocal Rank Fusion (RRF): Mathematically merges lexical and vector rankings ($k = 60$).
  • Maximal Marginal Relevance (MMR): Suppresses redundant chunks to maximize context window diversity ($\lambda = 0.75$).
• 📄 Native Multimodal Ingestion:
  • PDF Documents: Page-aware extraction with section boundaries using pdfbox-android.
  • Images & Scans: On-device Optical Character Recognition (OCR) via Google ML Kit.
  • Plain Text & Markdown: Native UTF-8 streaming parser.
• 🎛️ Fully User-Configurable:
  • Persistent user profile and customizable role/specialty.
  • Real-time temperature slider (0.00 deterministic to 1.00 creative).
  • Response length limit (256, 512, 1024, 2048, 4096 tokens).
  • Configurable Top-K retrieval chunks ($k = 1, 2, 3, 5, 8$) and similarity cutoff threshold.
• 💎 Refined Dark Interface: Clean charcoal surfaces (#212121, #171717, #2F2F2F) inspired by modern minimalist design with smooth streaming auto-scroll, code copy buttons, and expandable citations.

---

🏗️ Architecture

                                  User Input / Document
                                            │
                                            ▼
┌────────────────────────────────────────────────────────────────────────────────────────┐
│                                   PRESENTATION                                         │
│   MainActivity ──► ChatScreen ──► MarkdownRenderer (Click-to-Copy, Math, Syntax)        │
│   KairoSidebarDrawer (Persistent Profile, Sessions, Pinning)                           │
│   SettingsScreen (Hyperparameters, Personas, Storage, Grounding)                       │
│   ModelSetupScreen (GGUF Downloads, Storage Stats, Real-time Validation)               │
└───────────────────────────────────────────┬────────────────────────────────────────────┘
                                            │
                                            ▼
┌────────────────────────────────────────────────────────────────────────────────────────┐
│                                      DOMAIN                                            │
│   DocumentRepository (PDFBox / ML Kit OCR)                                             │
│       └── DocumentStructureParser (Heading & Breadcrumb Hierarchy)                     │
│               └── Chunker (Sliding-window with context retention)                      │
│                                                                                        │
│   RetrievalService                                                                     │
│       ├── Bm25SearchEngine (Sparse Lexical Search)                                    │
│       ├── EmbeddingService (Dense Neural Embeddings)                                  │
│       ├── ReciprocalRankFusion (Mathematical Multi-List RRF)                           │
│       └── MaximalMarginalRelevance (MMR Diversity Optimization)                        │
│                                                                                        │
│   RagPromptBuilder (Persona Injection: Clinical, Dev, Analyst, Custom)                 │
└───────────────────────────────────────────┬────────────────────────────────────────────┘
                                            │
                                            ▼
┌────────────────────────────────────────────────────────────────────────────────────────┐
│                                       DATA                                             │
│   KairoPreferences (Persistent SharedPreferences Configuration Engine)                 │
│   ConversationStore (Session History, Pinned Chats, Timestamps)                        │
│   ChunkStore (In-Memory Inverted Index & Chunk Embeddings)                             │
│   RunAnywhere SDK + LlamaCPP (Native GGUF Inference Engine)                            │
└────────────────────────────────────────────────────────────────────────────────────────┘

---

🚀 Quick Start: Running Kairo

1. Prerequisites

• Android Studio: Ladybug (2024.2.1) or newer.
• JDK: Java 17 or 21.
• Android Device: Physical device with ARM64-v8a processor and 6GB+ RAM recommended (Android 10+, API 29+).

2. Clone and Open

git clone https://github.com/<your-username>/Kairo.git
cd Kairo

Open the project folder in Android Studio and let Gradle sync.

3. Build & Run from Command Line

# Windows
.\gradlew.bat assembleDebug

# Install directly to connected device:
adb install -r app/build/outputs/apk/debug/app-debug.apk

# macOS / Linux
./gradlew assembleDebug
adb install -r app/build/outputs/apk/debug/app-debug.apk

---

⚙️ Configuring Kairo for Your Use Case

Anyone can configure Kairo to match their device capabilities or clinical/domain requirements:

A. Adjusting Settings in App

1. Open the sidebar drawer and tap the Profile Card or the Settings icon.
2. Profile & Identity: Set your display name (e.g. Dr. Alex Carter) and role (Cardiology Fellow).
3. Workflow Persona:
   • Choose Clinical / Consultation to evaluate patient reports with grounded symptom analysis.
   • Choose Code & Engineering for technical software questions.
   • Choose Custom Instructions to paste your own system prompt.
4. Inference Parameters:
   • Set Temperature to 0.10 for strict, deterministic medical/legal extraction.
   • Set Max Output Tokens to 1024 or 2048 to prevent long responses from cutting off.
   • Adjust Top-K Chunks ($k=1$ to $k=8$) depending on how much reference context your document requires.

B. Registering Additional GGUF Models in Code

You can add any compatible GGUF model hosted on Hugging Face or locally by editing KairoApp.kt:

RunAnywhere.models.register(
    ModelRegistration.url(
        id = "my-custom-model",
        name = "My Custom Model (Q4_K_M)",
        url = "https://huggingface.co/path/to/model-Q4_K_M.gguf",
        framework = InferenceFramework.INFERENCE_FRAMEWORK_LLAMA_CPP,
        memoryBytes = 600_000_000L,
        downloadBytes = 550_000_000L,
    )
)

---

🧪 Testing

Kairo includes an automated test suite verifying parser accuracy, BM25 scoring, Reciprocal Rank Fusion, sliding-window chunking, and prompt persona builders:

# Run all unit tests
.\gradlew.bat testDebugUnitTest

---

🤝 Contributing

Contributions are warmly welcomed! Please read our Contributing Guidelines and Code of Conduct before submitting pull requests.

---

📄 License

Kairo is released under the Apache License, Version 2.0. You are free to use, modify, distribute, and commercialize this software according to the terms of the Apache 2.0 license.
